Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Shenzhen Jiangfan Communication Equipment Co., Ltd.
Contact Now

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Brand Name : GAPHO

Model Number : FZQ-04 Optical cable splitter

Place of Origin : China

MOQ : 100

Price : negotiate

Payment Terms : T/T

Supply Ability : 50000

Delivery Time : 7-10 day

Packaging Details : Carton

Product Material : Steel/Aluminum/Copper/Plastic

Cable Diameter : 3-8mm;3-12mm

Product Diame : 10mm-18mm

Product Lenths : 20mm-50mm

Core Diame : 0.9mm-3.0mm

core NO. : 6/8/12/24/36/48core

place of origin : ShenZhen,CHINA

brand name : GAPHO

Accessories : Metal Ring, Heat Shrinkable Tube, Glue

diameter X lengths : φ11.4*40;14*50;14*45

Contact Now

FZQ-04 Optical cable Bundle splitter

Fiber Optic Fan Out Kit,FZQ-04 core dia 0.9-3.0mm,waterproof cables,armored cables,outdoor cables,stainless steel

Material available:stainless steel/aluminum alloy/copper/iron/POM

Surface treatment:anodizing,electroplating,spray molding,passivation,laser laser LOGO

Color:conventional color is blank,sliver white,customizable in any other color.It is suitable for all round indoorcables,outdoor cables,waterproof cables,armored cables,photoelecric composite cables and FTTH cables.

Accessories:heat shrinkable tube,glue,protective sleeve,fixing ring,screw,spanner.

Application:

  • Bunch cable branch
  • Armored fiber optic cable branch
  • Field optical cable branch
  • Various optical/cable branch solutions

Features:

  • Material non-metal black
  • POM material
  • High temperature resistant to ROHS
  • Fast and easy fixing

Product structure dimension drawing:

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

FZQ-03 Specifications:

Product Code φOD x L Specification cable dia product material
FZQ-04-01 11.4*40 6core2.0 3-8mm Steel/Aluminum/Copper/Plastic
FZQ-04-02 14*45 6core3.0 3-8mm Steel/Aluminum/Copper/Plastic
FZQ-04-03 11.4*40 8core2.0 3-8mm Steel/Aluminum/Copper/Plastic
FZQ-04-04 14*45 8core3.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-05 10*33 12core0.9 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-06 14*45 12core2.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-07 18*45 12core3.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-08 15*45 16core2.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-09 22*45 16core3.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-10 14*38 24core0.9 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-11 18*48 24core2.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-12 26*58 24core3.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-13 24*53 36core2.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-14 26*57 48core2.0 3-12mm Steel/Aluminum/Copper/Plastic
FZQ-04-15 31*80 72core2.0 3-12mm Steel/Aluminum/Copper/Plastic


FZQ-03 product ordering information:

Core No. OD2

Core Dia OD2

OD

Cable Dia

OD1

Product Dia

L

Product Lenths

material

1 2core 1 0.9mm 1 3.0mm 1 10mm 1 20mm 1 POM
2 4core 2 1.6mm 2 5.0mm 2 12mm 2 35mm 2 Aluminum alloy
3 6core 3 2.0mm 3 7.0mm 3 14mm 3 43mm 3 copper
4 8core 4 3.0mm 4 Other 4 18mm 4 50mm 4 Stainless steel
5 12core 5 Other 5 Other 5 Other 5 Other
6 24core
7 Other

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor
Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor
Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Other Products:Optical fiber adapter

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor

Core Dia 0.9-3.0mm Fiber Optic Fan Out Kit Waterproof Armored Cables Outdoor
